• Black painted steel front bumper w/grained MIC top cover-inc: bumper extenders & black front fender moldings
• Front fender vents
• Black painted grille
• Sealed beam halogen headlights
• Roof clearance lights
• Manual telescoping trailer tow mirrors w/manual glass & 2-way fold
• Solar tinted glass
• Variable intermittent windshield wipers
• Black door handles

• HD vinyl reclining bench seat
• Vinyl rear fold-forward bench seat
• Black vinyl full floor covering
• Color-coordinated scuff plates
• Black vinyl steering wheel
• Black instrument cluster w/black gauges & white graphics
• Inside hood release
• AM/FM stereo-inc: digital clock, (2) speakers
• Dash-top tray
• Color-coordinated instrument panel w/glove box, (4) air registers w/positive shutoff, ashtray & cigar lighter & (4) upfitter switches
• Auxiliary pwr point
• Dual front grab handles
• Front/rear passenger roof ride handles
• Color-coordinated molded cloth headliner
• 11.5" day/night rearview mirror
• Color-coordinated door trim panel-inc: armrest, grab handle, reflector
• Color-coordinated cloth sun visors-inc: LH pocket, RH mirror insert
• Door activated dome lamp w/delay, I/P switch operation
• Front/rear dual map lights
• Dual color-coordinated coat hooks

• Pwr 4-wheel anti-lock disc brakes w/hydro boost
• Driver/front passenger airbag
• Color-coordinated 3-point safety belts w/front outboard height adjustment
• Child tethers on all passenger seats
• Dual-note electric horn

6.4L OHV V8 POWER STROKE DIESEL ENGINE

135-amp HD alternator dual 78 amp/hr 750 CCA battery I/P air filter minder turbo boost gauge *Includes Winter Front Grille Cover in AK CO ID IA ME MI MN MT NH NY ND SD VT WI WY*

• 4.88 Axle Ratio
• GVWR: 16,000 lb Payload Package
• Prem. ETR AM/FM Stereo w/Single CD/MP3
• 4-Wheel Disc Brakes
• Dual rear wheels
• Front beverage holders
• Variably intermittent wipers
• Trip computer
• Rear reading lights
• Rear anti-roll bar
• Power steering
• Passenger vanity mirror
• Front reading lights
• Front anti-roll bar
• Dual front impact airbags
• AM/FM radio
• ABS brakes
• Voltmeter
• Tachometer

• Electrical
• Cold Cranking Amps @ 0° F (Primary): 750
• Cold Cranking Amps @ 0° F (2nd): 750
• Maximum Alternator Capacity (amps): 135
• Maximum Alternator Capacity (amps): 115
• Maximum Alternator Watts: - TBD -
• Maximum Alternator Watts: 1725
• Cooling System
• Total Cooling System Capacity (qts): 30.5
• Total Cooling System Capacity (qts): 27.5
• Weight Information
• Gross Axle Wt Rating - Front (lbs): 6000
• Gross Axle Wt Rating - Front (lbs): 5600
• Gross Axle Wt Rating - Rear (lbs): 12000
• Curb Weight - Front (lbs): 4849
• Curb Weight - Front (lbs): 4221
• Curb Weight - Rear (lbs): 3411
• Curb Weight - Rear (lbs): 3224
• Gross Vehicle Weight Rating Cap (lbs): 16000
• Gross Combined Wt Rating (lbs): 26000
• Trailering
• Dead Weight Hitch - Max Trailer Wt. (lbs): 5000
• Dead Weight Hitch - Max Tongue Wt. (lbs): 500
• Wt Distributing Hitch - Max Trailer Wt. (lbs): 16000
• Wt Distributing Hitch - Max Tongue Wt. (lbs): 2400
• Fifth Wheel Hitch - Max Trailer Wt. (lbs): 16500
• Fifth Wheel Hitch - Max Trailer Wt. (lbs): 17400
• Fifth Wheel Hitch - Max Tongue Wt. (lbs): 4125
• Fifth Wheel Hitch - Max Tongue Wt. (lbs): 4350
• Suspension
• Suspension Type - Front: Coil Spring
• Suspension Type - Rear: Multi-Leaf
• Spring Capacity - Front (lbs): 6000
• Spring Capacity - Front (lbs): 5600
• Spring Capacity - Rear (lbs): 12000
• Axle Type - Front: Mono-beam
• Axle Type - Rear: Full-Floating
• Axle Capacity - Front (lbs): 7000
• Axle Capacity - Rear (lbs): 12000
• Axle Ratio (:1) - Front: 4.88
• Axle Ratio (:1) - Rear: 4.88
• Shock Absorber Diameter - Front (mm): 35
• Shock Absorber Diameter - Rear (mm): 35
• Stabilizer Bar Diameter - Front (in): - TBD -
• Stabilizer Bar Diameter - Rear (in): - TBD -
• Brakes
• Brake Type: Pwr
• Brake ABS System: 4-Wheel
• Disc - Front (Yes or ): Yes
• Disc - Rear (Yes or ): Yes
• Front Brake Rotor Diam x Thickness (in): 14.53 x 0.47
• Rear Brake Rotor Diam x Thickness (in): 15.35 x 0.47
• Tires
• Front Tire Order Code: TFB
• Rear Tire Order Code: TFB
• Front Tire Size: 225/70R19.5F
• Rear Tire Size: 225/70R19.5F
• Front Tire Capacity (lbs): 3415
• Rear Tire Capacity (lbs): 3415
• Revolutions/Mile @ 45 mph - Front: 653
• Revolutions/Mile @ 45 mph - Rear: 653
• Wheels
• Front Wheel Size (in): 19.5 x 6.0
• Rear Wheel Size (in): 19.5 x 6.0
• Front Wheel Material: Steel
• Rear Wheel Material: Steel
• Steering
• Steering Type: Pwr
• Steering Ratio (:1), On Center: 18.0
• Steering Ratio (:1), At Lock: - TBD -
• Turning Diameter - Curb to Curb (ft): 51.5
• Turning Diameter - Wall to Wall (ft): 53.3
• Frame
• Frame Type: Ladder
• Fuel Tank
• Fuel Tank Capacity, Approx (gal): 40.0
• Fuel Tank Location: Aft-Axle
• Exterior Dimensions
• Wheelbase (in): 176.2
• Length, Overall w/o rear bumper (in): 261.4
• Width, Max w/o mirrors (in): 93.9
• Height, Overall (in): 80.2
• Overhang, Front (in): 37.6
• Overhang, Rear w/o bumper (in): 47.6
• Front Bumper to Back of Cab (in): 153.8
• Cab to Axle (in): 60.0
• Cab to End of Frame (in): 107.6
• Ground to Top of Frame (in): 32.5
• Frame Width, Rear (in): 34.2
• Ground Clearance, Front (in): - TBD -
• Ground Clearance, Rear (in): 7.9
• Interior Dimensions
• Passenger Capacity: 6
• Front Head Room (in): 41.4
• Front Leg Room (in): 41.0
• Front Shoulder Room (in): 68.0
• Front Hip Room (in): 67.6
• Second Head Room (in): 41.4
• Second Leg Room (in): 41.8
• Second Shoulder Room (in): 68.0
• Second Hip Room (in): 67.3
• Summary
• Vehicle Name: Ford Super Duty F-450 DRW
• Body Style: Crew Cab
• Body Code: 176" WB
